NCCL Tuning for Multi-GPU LLM Training: Environment Variables, Topology, and Cloud Guide (2026)

On a well-provisioned 8x H100 SXM5 node, NCCL all-reduce accounts for 20-30% of total training step time with default settings. On a misconfigured cluster, that number climbs to 40-50%. The hardware is not the problem. NCCL's default configuration is deliberately conservative, tuned for compatibility across many topologies rather than peak performance on any specific one. This guide covers what to change, why, and how to verify the result. For background on the underlying network fabrics, see GPU Networking for AI Clusters and Multi-Node GPU Training Without InfiniBand.

All examples below were tested with NCCL 2.21.x, which ships with CUDA 12.4 and is the current standard as of April 2026. Variable behavior differs in older versions (2.18 and earlier); call-outs for version-specific behavior appear inline.

What NCCL Does and Why It Determines Your Training Ceiling

NCCL handles collective communication operations across GPUs. In data-parallel training, every GPU computes gradients on its local batch. Before the optimizer step, those gradients must be averaged across all GPUs, so that every replica applies the same update. That averaging operation is all-reduce.

All-reduce in NCCL is split into two phases. First, reduce-scatter: each GPU sends one chunk of its gradient tensor to every other GPU while simultaneously receiving chunks from others, so every GPU ends up with a fully summed slice of the total gradient. Second, all-gather: each GPU broadcasts its slice to every other GPU, so all GPUs end up with the full averaged gradient. Total communication volume per GPU is 2 * (N-1)/N * bytes_per_tensor, where N is the number of GPUs.

For a 70B model, ~19.6s all-reduce per step on 100GbE is 50-100% of a typical 20-40s step. That is the ceiling you are trying to move.

NCCL defaults to conservative settings because it runs on many topologies: nodes connected via PCIe with no NVLink, mixed HCA types, VMs with virtualized NICs. The defaults work everywhere and perform well nowhere. Tuning means telling NCCL what your actual topology is so it stops making worst-case assumptions.

Topology Discovery: nvidia-smi topo, NCCL_TOPO_DUMP_FILE

Before changing any NCCL variable, understand what your hardware looks like.

nvidia-smi topo -m

The matrix shows connectivity between every pair of GPUs and between GPUs and NICs. The connection type codes matter:

NVLink generations by GPU: H100 and H200 use NVLink 4 (900 GB/s aggregate per GPU); B200 uses NVLink 5 (1.8 TB/s). The NVx number in the topology matrix is the connection count, not the NVLink generation.

For an 8x H100 HGX system, you want every GPU-to-GPU pair to show NV18 (NVSwitch). GPU-to-NIC entries typically show SYS or NODE. SYS between a GPU and NIC is normal; it just means there is a NUMA hop, and NCCL_NET_GDR_LEVEL controls whether NCCL optimizes that path with GPUDirect RDMA.

# Example nvidia-smi topo -m output for 8x H100 SXM5 HGX

        GPU0  GPU1  GPU2  GPU3  GPU4  GPU5  GPU6  GPU7  mlx5_0  mlx5_1
GPU0     X    NV18  NV18  NV18  NV18  NV18  NV18  NV18   SYS     SYS
GPU1    NV18   X    NV18  NV18  NV18  NV18  NV18  NV18   SYS     SYS
GPU2    NV18  NV18   X    NV18  NV18  NV18  NV18  NV18   SYS     SYS
GPU3    NV18  NV18  NV18   X    NV18  NV18  NV18  NV18   SYS     SYS
GPU4    NV18  NV18  NV18  NV18   X    NV18  NV18  NV18   SYS     SYS
GPU5    NV18  NV18  NV18  NV18  NV18   X    NV18  NV18   SYS     SYS
GPU6    NV18  NV18  NV18  NV18  NV18  NV18   X    NV18   SYS     SYS
GPU7    NV18  NV18  NV18  NV18  NV18  NV18  NV18   X     SYS     SYS

All GPU-to-GPU pairs show NV18 (NVLink via 18-port NVSwitch), which means all intra-node communication goes through NVSwitch at full bandwidth. Both NICs (mlx5_0, mlx5_1) show SYS to all GPUs, meaning they cross a NUMA boundary. This is normal for HGX nodes.

For NCCL's view of topology, export it:

NCCL_TOPO_DUMP_FILE=/tmp/nccl_topo.xml python train.py

Open the XML and look at the tree structure. Each GPU sub-tree lists the NICs it can reach and via what path. If mlx5_0 only appears under GPU0-GPU3's sub-tree and mlx5_1 only under GPU4-GPU7, setting NCCL_IB_HCA=mlx5_0:1,mlx5_1:1 pins each GPU group to the NIC with the lowest-latency path.

NVLink vs PCIe vs NIC Paths

On H100/H200 SXM HGX nodes, NVSwitch connects all 8 GPUs in a full-mesh. The NVSwitch fabric runs at 900 GB/s bidirectional per GPU for H100 and H200 (NVLink 4) and 1.8 TB/s for B200 (NVLink 5). Intra-node all-reduce never touches PCIe or the NICs.

Inter-node all-reduce goes: GPU HBM -> NVSwitch -> NIC (via PCIe or direct GDR path) -> InfiniBand fabric -> remote NIC -> remote NVSwitch -> remote GPU HBM. NCCL's job is to select the fastest path at each segment. The variables below control each step.

The Most Impactful NCCL Environment Variables

NCCL_ALGO

Selects the all-reduce algorithm. Options: Ring, Tree, CollNet (NCCL 2.19+, requires SHARP-enabled IB switches), NVLS (NVLink SHARP, Hopper+).

export NCCL_ALGO=Ring  # for most 8-32 GPU clusters

Ring is bandwidth-optimal for small-to-medium clusters because every link carries equal traffic. Tree uses fewer round-trips but creates unequal link load, with root links carrying the most. For clusters beyond 32 nodes, Tree's latency advantage outweighs Ring's bandwidth evenness. Leave it unset and benchmark both before committing.

NCCL_PROTO

Controls the communication protocol within a transport. Simple has the lowest overhead and is best for high-bandwidth InfiniBand. LL (Low Latency) reduces latency for small messages. LL128 is a 128-byte low-latency variant that works well for intra-node NVLink. NCCL typically auto-selects correctly; override only if benchmarks show a regression.

export NCCL_PROTO=Simple  # for IB inter-node

NCCL_P2P_LEVEL

Controls how deep in the topology tree NCCL will attempt direct peer-to-peer GPU transfers.

export NCCL_P2P_LEVEL=SYS  # allow P2P across NUMA and NVSwitch boundaries

On HGX nodes with NVSwitch, all GPU-to-GPU traffic is P2P via NVSwitch. The default auto usually detects this correctly, but SYS forces NCCL to use the full topology depth. If you set this and busbw drops, your topology does not actually support full P2P (common on PCIe-only nodes or some VM configurations).

NCCL_NET_GDR_LEVEL

Controls how deep NCCL will use GPUDirect RDMA when transferring data between GPU memory and NICs.

export NCCL_NET_GDR_LEVEL=5  # allow GDR across all PCIe/NUMA boundaries

Value 0 disables GDR entirely. Value 5 allows GDR regardless of topology distance. The default of 2 restricts GDR to paths within the same PCIe complex, which excludes most GPU-to-NIC paths on HGX nodes (where NICs and GPUs are in different NUMA domains). Setting to 5 enables GDR across the full node, provided nvidia_peermem is loaded.

NCCL_BUFFSIZE

The per-connection ring buffer for NCCL communication. Larger buffers reduce pipeline stalls on long all-reduce operations.

export NCCL_BUFFSIZE=16777216  # 16MB, up from 4MB default

For gradient tensors in the 1-10GB range (common at 70B+ scale), the default 4MB causes frequent buffer exhaustion and pipeline stalls. 16MB is a good starting point; some teams go to 32MB for very large tensors. Watch GPU memory consumption: NCCL allocates this buffer per communicator.

NCCL_NTHREADS

CUDA thread count per collective operation kernel.

export NCCL_NTHREADS=512  # for B200 NVLink 5 nodes

The default 256 threads per SM block cannot saturate B200's 1.8 TB/s NVLink 5. On H100/H200 with NVLink 4 (900 GB/s), 256 is usually sufficient. Increase to 512 on B200 nodes if nccl-tests shows busbw below 85% of theoretical peak.

NCCL_ASYNC_ERROR_HANDLING

Default 0 means hangs are silent. The training job stops making progress and you have no signal. Note: this variable is read by PyTorch's ProcessGroupNCCL wrapper, not by libnccl itself, so it only takes effect when training through PyTorch. In PyTorch 2.2+, the canonical name is TORCH_NCCL_ASYNC_ERROR_HANDLING; the old name still works for backward compatibility.

export NCCL_ASYNC_ERROR_HANDLING=1  # always set this (PyTorch reads this; renamed TORCH_NCCL_ASYNC_ERROR_HANDLING in PyTorch 2.2+)

With value 1, PyTorch converts collective timeouts into Python exceptions that surface to your training loop. Combined with NCCL_TIMEOUT, this is your hang detection system.

NCCL_TIMEOUT

Maximum seconds for a collective to complete before NCCL raises an error (requires NCCL_ASYNC_ERROR_HANDLING=1).

export NCCL_TIMEOUT=1800  # 30 minutes for long training steps

Default 0 means no timeout. For large all-reduce on 405B-scale models, a single collective can take minutes. Set this to 2-3x your expected worst-case collective duration, not to a tight value that triggers false positives on slow steps.

InfiniBand Settings: NCCL_IB_HCA, NCCL_IB_GID_INDEX, NCCL_IB_TIMEOUT

NCCL_IB_HCA

The single most impactful InfiniBand variable. It tells NCCL which HCAs to use for inter-node communication.

On an 8xH200 node with two ConnectX-7 HCAs (mlx5_0 and mlx5_1), each NIC is wired to serve a subset of GPUs in the same NUMA domain. If NCCL auto-selects the wrong NIC for a GPU group, each inter-node packet takes an extra NUMA hop through the PCIe switch and across the QPI/UPI interconnect. That adds 1-3 microseconds per collective call, which compounds into seconds per training step at scale.

# Find your HCA names
ibstat

# Cross-reference with GPU topology
nvidia-smi topo -m

# Pin NCCL to the HCAs with GPU affinity
export NCCL_IB_HCA=mlx5_0:1,mlx5_1:1

The :1 suffix after each HCA name specifies port 1 (most single-port HCAs have only port 1). For dual-port HCAs, you can specify mlx5_0:1,mlx5_0:2 to use both ports.

On Spheron H200 and H100 bare-metal nodes, you get direct HCA access with the full ibstat output and direct HCA configuration. On hyperscaler VMs, the HCA is virtualized and NCCL_IB_HCA is often ignored or unavailable.

NCCL_IB_GID_INDEX

For RoCEv2 clusters, the GID (Global Identifier) index selects the IP address type used for RDMA connections.

export NCCL_IB_GID_INDEX=3  # RoCEv2 with IPv4-mapped IPv6 GID

GID index 0 is the InfiniBand GID (for native IB). Index 1 is RoCEv1. Index 3 is typically RoCEv2 with IPv4-mapped IPv6. The exact index depends on your NIC firmware and OS configuration; check show_gids output to confirm which index corresponds to RoCEv2. Since NCCL 2.21.5, NCCL auto-selects GID index -1 (automatic), which works for most RoCEv2 setups. Only override if auto-selection is picking the wrong GID type.

NCCL_IB_TIMEOUT

Timeout for IB completion queue polling. Default 14 (as an exponent: 4.096μs × 2^value, so ~67ms). At large cluster scale, fabric congestion can cause completion latencies beyond this threshold, resulting in spurious timeout errors.

export NCCL_IB_TIMEOUT=22  # ~17.2s, better for 64+ node clusters

For 8-16 node clusters on uncongested fabric, the default is fine. For 64+ node clusters where fabric congestion is unavoidable during all-reduce, increase this to avoid false timeouts.

Complete IB env var block for a dual-HCA H200 node:

# InfiniBand NCCL settings for 8xH200 SXM5 HGX, NCCL 2.21.x
export NCCL_IB_DISABLE=0
export NCCL_IB_HCA=mlx5_0:1,mlx5_1:1   # both ConnectX-7 HCAs, port 1
export NCCL_IB_GID_INDEX=3              # only set if auto-selection picks wrong GID; on NCCL 2.21.5+ usually unnecessary
export NCCL_IB_TIMEOUT=22               # ~17.2s, for congested fabrics
export NCCL_IB_RETRY_CNT=7             # retransmit up to 7 times before error
export NCCL_NET_GDR_LEVEL=5            # full GPUDirect RDMA (requires nvidia_peermem)

GDRDMA: When GPU Direct RDMA Helps vs Hurts

GPUDirect RDMA (GDR) allows the NIC's DMA engine to read from and write to GPU HBM directly, bypassing system memory. The standard NCCL path for inter-node traffic is: GPU HBM -> CPU DRAM (bounce buffer) -> NIC. With GDR enabled: GPU HBM -> NIC directly. For large messages (>512KB), removing the bounce buffer saves one full memory copy per direction, typically 10-20% of inter-node communication time.

Prerequisites for GDR:

1. nvidia_peermem kernel module must be loaded: lsmod | grep nvidia_peermem
2. NIC driver must support GDR (Mellanox OFED 5.1+ for ConnectX-6 and later)
3. IOMMU must be either disabled or configured in passthrough mode for the GPU/NIC PCIe devices
4. GPUs and NICs must be in the same PCIe domain (or NCCL_NET_GDR_LEVEL=5 to override)

Verify GDR is active:

lsmod | grep nvidia_peermem
# Should show: nvidia_peermem  <size>  0

# Then check NCCL_DEBUG=INFO output for:
# NCCL INFO GDR memory type: CUDA
# If you see: NCCL INFO GDR memory type: HOST
# ...GDR is not active even if the variable is set

When GDR helps: Message sizes above 512KB on InfiniBand fabric where nvidia_peermem is confirmed loaded. On bare-metal H100/H200 nodes, GDR typically improves inter-node busbw by 15-25% on 2GB+ tensors.

When GDR hurts or has no effect:

• VMs with SR-IOV virtual function NICs: the hypervisor NIC virtualization layer breaks the direct GPU-NIC DMA path. Set NCCL_NET_GDR_LEVEL=0 on VMs.
• NIC drivers that report GDR support but have incomplete implementation: busbw drops instead of improving. If enabling GDR reduces performance, disable it.
• PCIe bandwidth is already the bottleneck: GDR helps the CPU-DRAM path, not PCIe. If your GPU-NIC PCIe path is already saturated, GDR will not help.

On Spheron bare-metal nodes, nvidia_peermem is loaded and GDR is available. On hyperscaler VMs, assume GDR is not available and leave NCCL_NET_GDR_LEVEL at 0 or 2.

Diagnosing Slow All-Reduce: NCCL_DEBUG Walkthrough

NCCL_DEBUG=INFO NCCL_DEBUG_SUBSYS=ALL python train.py 2>&1 | tee nccl_debug.log

Key lines to look for in the output:

# Which algorithm NCCL selected
NCCL INFO comm 0x7f... rank 0 nranks 8 cudaDev 0 - Init COMPLETE
NCCL INFO AllReduce: opCount 1 sendbuff 0x... recvbuff 0x... count 536870912 datatype 8 op 0 root 0 comm 0x... [nranks=8] stream 0x...
NCCL INFO Algorithm Ring, Protocol Simple
# ^ If you see LL or LL128 on IB inter-node, consider forcing Simple
# If you see Tree on a small cluster, consider forcing Ring

# GDR status
NCCL INFO GDR memory type: CUDA  # GDR active
NCCL INFO GDR memory type: HOST  # GDR not active, bounce buffer in use

To identify the slowest collective, compare timestamps in NCCL_DEBUG=INFO output. The gap between successive AllReduce lines is the collective duration. On a tuned cluster, all-reduce on a 2GB tensor should complete in under 100ms at 400Gbps InfiniBand.

Diagnostic tricks:

# Disable P2P to test if P2P path is helping or hurting
NCCL_P2P_DISABLE=1 python train.py

# If disabling P2P speeds things up, your P2P path is misconfigured
# (common on nodes where NVLink is not fully enabled)

# Extract algorithm selection from debug log
grep "Algorithm" nccl_debug.log | sort | uniq -c
# Shows how often NCCL chose Ring vs Tree vs CollNet

# Check for error messages
grep -i "error\|warn\|fail" nccl_debug.log

For production, use NCCL_DEBUG=WARN rather than INFO. The WARN level captures configuration problems and errors without logging a line per collective call (INFO output is gigabytes per hour on large clusters).

Ring, Tree, SHARP, and PXN: Algorithm Deep Dive

Ring

All-reduce with ring algorithm: each GPU passes data to the next GPU in a ring, one chunk at a time. After N-1 rounds of reduce-scatter, each GPU holds a fully summed slice. After another N-1 rounds of all-gather, every GPU has the complete averaged tensor. Total data transferred per GPU: 2 * (N-1)/N * tensor_bytes. Bus bandwidth utilization approaches 100% of network bandwidth at large message sizes.

Ring is optimal for 2-32 nodes because link utilization is uniform and latency scales linearly with N. At 64+ nodes, the 2*(N-1) round-trip count becomes a meaningful latency penalty.

Tree

Tree reduces latency by using a log(N) depth tree structure. Data flows up the tree (reduce phase) then back down (broadcast phase). Total rounds: 2 * log2(N). For N=64, Ring needs 126 rounds; Tree needs 12. But the root link carries the full gradient tensor in both directions, creating a hot-link bottleneck. Tree outperforms Ring when latency dominates over bandwidth, which happens at N > 32-64 nodes.

CollNet / SHARP

CollNet (NCCL 2.19+) uses SHARP (Scalable Hierarchical Aggregation and Reduction Protocol) to perform the all-reduce reduction inside InfiniBand switch ASICs. Instead of routing gradients to all nodes and summing in GPU memory, the switches sum the data in-flight. GPUs send gradients once and receive results once. Communication volume per GPU: (N-1)/N * tensor_bytes (half of Ring).

Requirements for CollNet/SHARP:

• NVIDIA Quantum-2 InfiniBand switches with SHARP firmware (smarts version)
• SHARP Aggregation Manager daemon (sharp_manager) running on the cluster
• ConnectX-6 Dx or ConnectX-7 HCAs
• Not universally available on all IB clusters; verify with your cluster admin before enabling

# Enable SHARP/CollNet (NCCL 2.19+)
export NCCL_ALGO=CollNet
export NCCL_COLLNET_ENABLE=1
export NCCL_IB_SHARP_ENABLE=1

If SHARP is not available on your switch fabric, NCCL will fall back to Ring silently. Check NCCL_DEBUG=INFO output for CollNet in the algorithm selection line to confirm SHARP is active.

PXN (Proxy Cross-NIC)

PXN enables NCCL to aggregate bandwidth across multiple NICs on a node by using GPU-to-GPU NVLink for the local aggregation step, then sending via any available NIC. On nodes with 4 NICs, PXN can quadruple inter-node bandwidth by using all NICs in parallel. Enable via:

export NCCL_PXN_DISABLE=0  # PXN enabled by default in NCCL 2.17+

For nodes with multiple HCAs set in NCCL_IB_HCA, PXN is the mechanism that uses them in parallel. If you set NCCL_IB_HCA=mlx5_0:1,mlx5_1:1 and only one NIC appears active in the NCCL debug log, PXN may be disabled or misconfigured.

Algorithm selection by cluster size:

FSDP, DeepSpeed ZeRO, and TP/PP: Per-Parallelism NCCL Settings

FSDP (PyTorch Fully Sharded Data Parallel)

FSDP shards model parameters across GPUs and reconstructs them via all-gather before each forward pass, then accumulates gradients via reduce-scatter. Every FSDP unit triggers two collectives per forward-backward: all-gather on entry, reduce-scatter on exit.

Critical settings for FSDP:

export NCCL_ASYNC_ERROR_HANDLING=1
export TORCH_NCCL_HEARTBEAT_TIMEOUT_SEC=1800
export TORCH_NCCL_ENABLE_MONITORING=1

The TORCH_NCCL_HEARTBEAT_TIMEOUT_SEC timeout works at the PyTorch level. The process watchdog thread checks for NCCL collective progress every heartbeat interval. If a collective does not complete, PyTorch raises an exception. Set this to match NCCL_TIMEOUT.

Deadlock pattern with FSDP + gradient checkpointing: Gradient checkpointing re-runs the forward pass during backward to save activation memory. If FSDP modules are nested and overlap with gradient checkpoint regions, the resulting collective call order can deadlock: one rank calls all-gather for a forward re-compute while another rank is already in a backward reduce-scatter for the same parameter. Fix: align FSDP unit boundaries with gradient checkpoint regions so they do not interleave.

# Wrong: FSDP units smaller than gradient checkpoint regions
model = FSDP(model, use_orig_params=True)  # may cause overlapping collectives

# Correct: align FSDP wrapping with checkpoint regions
def wrap_policy(module, recurse, nonwrapped_numel):
    return isinstance(module, TransformerBlock)  # same granularity as checkpoint

model = FSDP(model, auto_wrap_policy=wrap_policy, use_orig_params=True)

DeepSpeed ZeRO

ZeRO Stage 3 moves all-gather and reduce-scatter of parameters into the optimizer step, similar to FSDP. Key DeepSpeed settings for NCCL performance:

{
  "zero_optimization": {
    "stage": 3,
    "overlap_comm": true,
    "contiguous_gradients": true,
    "reduce_bucket_size": 5e8
  }
}

overlap_comm: true starts the next all-reduce while the previous one is still completing, hiding latency. reduce_bucket_size controls how many gradient bytes are accumulated before an all-reduce is triggered. Smaller buckets mean more frequent but smaller collectives (lower latency, less throughput). Larger buckets mean fewer collectives with more data each (higher throughput, more memory usage). For 8-GPU training, 500MB is a reasonable starting point.

Setting NCCL_TREE_THRESHOLD prevents oscillation between Ring and Tree algorithms on large ZeRO-3 runs where message sizes vary widely:

export NCCL_TREE_THRESHOLD=0  # always use Ring (disable Tree entirely)
# Or: set a threshold in bytes above which NCCL switches to Tree
export NCCL_TREE_THRESHOLD=4294967296  # 4GB threshold

Tensor Parallelism (TP)

Tensor parallelism splits individual weight matrices across GPUs and uses all-reduce after each matrix multiply. This is intra-node only in most frameworks (Megatron-LM, vLLM), using NVLink directly via NCCL_P2P_LEVEL=SYS. For vLLM inference with tensor parallelism, the dominant NCCL setting is NCCL_P2P_LEVEL=SYS to use NVSwitch for the all-reduce.

TP process groups use a separate NCCL communicator from DP process groups. Do not share communicators between parallelism dimensions; the initialization order matters for deadlock avoidance.

Pipeline Parallelism (PP)

Pipeline parallelism sends activations point-to-point between stages, not via collective all-reduce. NCCL environment variables have much less impact here. Focus instead on NCCL_SOCKET_NTHREADS (thread count for socket-based transport) and ensuring correct NCCL_SOCKET_IFNAME selection for the inter-stage communication interface.

Avoiding Classic NCCL Hangs

Root causes:

1. Asymmetric collectives: rank 0 calls all_reduce, rank 1 calls broadcast. Both block waiting for the other to enter the same collective. NCCL collectives must be called in the same order across all ranks with matching operation types and tensor shapes.

2. OOM on one rank: PyTorch raises a CUDA OOM exception on rank 3, which kills that process. Ranks 0, 1, 2, 4-7 are still waiting for rank 3 to participate in the next all-reduce. They wait indefinitely with no signal.

3. Mismatched communicator keys: Two processes join the same NCCL communicator with different ncclUniqueId values. Common when dist.init_process_group is called before all processes are ready and some ranks use a stale rendezvous key.

Detection setup:

export NCCL_ASYNC_ERROR_HANDLING=1
export NCCL_TIMEOUT=1800
export TORCH_NCCL_HEARTBEAT_TIMEOUT_SEC=1800
export NCCL_DEBUG=WARN  # captures errors without flooding logs

Monitoring in production: Watch for GPU utilization dropping to 0% across all ranks simultaneously while the process is still running. This is the hang signature. Use nvidia-smi dmon -s u -d 10 to log utilization every 10 seconds. If all GPUs drop to 0% for more than 60 seconds during training, it is almost certainly an NCCL hang, not a checkpoint write or data loading pause.

Cloud-Specific Gotchas: Containers, Kubernetes, and Virtualized NICs

Containers

NCCL uses POSIX shared memory for intra-node peer-to-peer data transfers. Containers by default have isolated IPC namespaces that block shared memory access between containers on the same host.

# Docker: enable IPC namespace sharing
docker run --ipc=host ...

# Or mount shm explicitly
docker run --shm-size=64g ...

Without --ipc=host, NCCL falls back to copying data through the network stack even for intra-node GPU-to-GPU transfers. This turns 900 GB/s NVLink into a 25 Gbps Ethernet path.

Kubernetes

For Kubernetes multi-GPU pods:

# Pod security context for RDMA/NCCL
securityContext:
  capabilities:
    add: ["IPC_LOCK"]
  privileged: false  # avoid full privileged mode; use specific capabilities

# For InfiniBand, request RDMA resources
resources:
  limits:
    nvidia.com/gpu: 8
    rdma/hca_shared_devices_a: 1  # or per your rdma-device-plugin config

Set NCCL_SOCKET_IFNAME explicitly to the pod's network interface. The default loopback (lo) or the container's virtual bridge (docker0) will not have the bandwidth or routing needed for multi-node communication.

export NCCL_SOCKET_IFNAME=eth0  # or eth1, ens4, etc. - check ip addr output in pod

For multi-node jobs, use PyTorch Distributed rendezvous via etcd or a Kubernetes init container that publishes the master address before the training containers start. See Kubernetes GPU Orchestration 2026 for cluster setup details.

Virtualized NICs and SR-IOV

Hyperscalers expose GPUs via SR-IOV virtual function NICs. The VF driver presents a NIC to the VM, but GPUDirect RDMA through a VF is not supported in most hypervisor configurations. The NIC-to-GPU DMA path goes through the hypervisor, defeating the purpose of GDR.

# For VMs with SR-IOV NICs: disable GDR
export NCCL_NET_GDR_LEVEL=0

# For VMs where NCCL_IB_HCA has no effect: do not set it
# The hypervisor controls NIC assignment; setting HCA manually can cause errors

On bare-metal Spheron nodes, you get direct HCA access. On a hyperscaler VM, ibstat shows a VF with a fake GUID and you cannot change NIC assignments. The practical difference: on bare-metal with optimal NCCL_IB_HCA assignment and GDR enabled, a typical 8-node all-reduce on a 2GB tensor runs at 85-90% of theoretical IB NDR bandwidth. On a hyperscaler VM with VF NICs, expect 50-60% of theoretical bandwidth after tuning, with GDR disabled.

Spheron 8xH200 Cluster: Topology Output, Tuned Env Vars, and 1.6x All-Reduce Speedup

Topology

# nvidia-smi topo -m on Spheron 8xH200 SXM5 HGX node

        GPU0  GPU1  GPU2  GPU3  GPU4  GPU5  GPU6  GPU7  mlx5_0  mlx5_1  CPU Affinity
GPU0     X    NV18  NV18  NV18  NV18  NV18  NV18  NV18   SYS     SYS    0-47
GPU1    NV18   X    NV18  NV18  NV18  NV18  NV18  NV18   SYS     SYS    0-47
GPU2    NV18  NV18   X    NV18  NV18  NV18  NV18  NV18   SYS     SYS    0-47
GPU3    NV18  NV18  NV18   X    NV18  NV18  NV18  NV18   SYS     SYS    0-47
GPU4    NV18  NV18  NV18  NV18   X    NV18  NV18  NV18   SYS     SYS    48-95
GPU5    NV18  NV18  NV18  NV18  NV18   X    NV18  NV18   SYS     SYS    48-95
GPU6    NV18  NV18  NV18  NV18  NV18  NV18   X    NV18   SYS     SYS    48-95
GPU7    NV18  NV18  NV18  NV18  NV18  NV18  NV18   X     SYS     SYS    48-95
mlx5_0  SYS   SYS   SYS   SYS   SYS   SYS   SYS   SYS    X      PIX
mlx5_1  SYS   SYS   SYS   SYS   SYS   SYS   SYS   SYS   PIX      X

Both HCAs (mlx5_0, mlx5_1) show SYS to all GPUs, meaning they cross NUMA boundaries. They are PIX to each other (same PCIe switch). For inter-node traffic, NCCL can use either HCA for any GPU. Setting NCCL_IB_HCA=mlx5_0:1,mlx5_1:1 enables both HCAs in parallel via PXN, doubling the inter-node bandwidth from one HCA's 400 Gbps to two HCAs' 800 Gbps effective.

ibstat output (abbreviated)

CA 'mlx5_0'
  Port 1:
    State: Active
    Physical state: LinkUp
    Rate: 400
    Link layer: InfiniBand
    ...
CA 'mlx5_1'
  Port 1:
    State: Active
    Physical state: LinkUp
    Rate: 400
    Link layer: InfiniBand

Both HCAs active at 400 Gbps NDR. Total available inter-node bandwidth: 800 Gbps per node.

Baseline NCCL settings (defaults)

# No custom NCCL settings; NCCL 2.21.x defaults
# NCCL auto-selects algorithm, protocol, one HCA

Tuned NCCL settings

# NCCL tuning for 8xH200 SXM5 on Spheron, NCCL 2.21.x
export NCCL_IB_DISABLE=0
export NCCL_IB_HCA=mlx5_0:1,mlx5_1:1   # both HCAs for 800Gbps aggregate
export NCCL_IB_GID_INDEX=3              # only set if auto-selection picks wrong GID; on NCCL 2.21.5+ usually unnecessary
export NCCL_IB_TIMEOUT=22              # ~17.2s - prevents spurious timeouts
export NCCL_NET_GDR_LEVEL=5           # full GDR (nvidia_peermem loaded)
export NCCL_P2P_LEVEL=SYS             # full NVSwitch P2P depth
export NCCL_BUFFSIZE=16777216         # 16MB buffer (up from 4MB)
export NCCL_ALGO=Ring                 # explicit ring for 2-8 node clusters
export NCCL_PROTO=Simple              # Simple protocol for IB inter-node
export NCCL_ASYNC_ERROR_HANDLING=1    # surface hangs as exceptions
export NCCL_TIMEOUT=1800              # 30 min timeout per collective
export TORCH_NCCL_HEARTBEAT_TIMEOUT_SEC=1800

nccl-tests results: before vs after

All-reduce performance across two 8xH200 nodes (16 GPUs total), NCCL 2.21.x, NDR 400G InfiniBand per node:

The 1.6x improvement on 8GB messages comes from: dual HCA usage via PXN (2x bandwidth), GDR eliminating the bounce buffer (15-20% improvement), and buffer size increase reducing stalls (5-10% improvement).

Llama 70B FSDP step time: before vs after

The all-reduce improvement does not translate 1:1 to step time improvement because compute still accounts for ~81% of total step time after tuning. But the ~9 percentage point reduction in compute-wait-on-communication translates to an 11% improvement in GPU utilization, which at $5.58/GPU/hr on-demand (or $1.19/GPU/hr spot) on 16 GPUs adds up.

GPU pricing (as of 27 Apr 2026)

Pricing fluctuates based on GPU availability. The prices above are based on 27 Apr 2026 and may have changed. Check current GPU pricing → for live rates.

For teams running Llama 70B FSDP training on 16x H200 at $5.58/GPU/hr on-demand, the 12% step time improvement from NCCL tuning translates to ~12% lower training cost with no hardware change. On a 7-day training run that is roughly 20 hours of GPU time recovered per 16-GPU node.

Rent H100 SXM5 rental if you are on a budget. Move to H200 GPU rental on Spheron once you are scaling past 8 GPUs or need the higher HBM capacity (141 GB vs 80 GB) for 70B+ models. B200 GPU rental is worth evaluating for teams that need NVLink 5 bandwidth for extreme-scale training and can tolerate the spot pricing volatility.

Bare-metal access matters for NCCL tuning. On Spheron H200 and H100 clusters, you can pin NCCL_IB_HCA to specific HCAs, load nvidia_peermem for GPUDirect RDMA, and inspect the full InfiniBand topology without hypervisor interference. Most managed clouds abstract this away, capping multi-node throughput.

Rent H200 → | Rent H100 → | Rent B200 → | View all pricing →
