Deploy Mooncake on GPU Cloud: KVCache-Centric Disaggregated Serving for 3.8x Higher vLLM Throughput (2026 Guide)

Agentic LLM workloads have a specific problem that standard prefill-decode disaggregation does not fully solve: the KV state from one step of an agent trace must survive and be reachable during a completely different decode step, possibly on a different GPU, possibly minutes later. At Kimi's production scale (thousands of nodes, 100B+ tokens per day) with 1M-token contexts, re-running prefill each time would dominate cost. Mooncake is how Moonshot AI solves this.

The benchmarks from the vLLM engineering blog (May 2026): 3.8x throughput gain, 46x lower TTFT, 8.6x lower end-to-end latency on agentic traces. These figures were measured on 12 GB200 (Grace Blackwell) GPUs. A separate scaling test in the same post ran to 60 GB200 GPUs and demonstrated >95% KV cache hit rate at that scale. On a 2-node H100+H200 cluster on Spheron, the absolute numbers will be lower, but the architectural advantage holds: the more unique KV state your workload accumulates, the more Mooncake's disaggregated pool beats simple in-GPU caching.

Mooncake joined the PyTorch Ecosystem in February 2026. vLLM added MooncakeStoreConnector in May 2026 as a native connector alongside NixlConnector and LMCacheConnector. This post covers both connectors, the hardware sizing, and the step-by-step deployment on Spheron's GPU cloud.

For KV cache fundamentals before going further, see the KV Cache Optimization Guide. For the base prefill-decode architecture this builds on, see prefill-decode disaggregation on GPU cloud.

TL;DR: Mooncake vs LMCache vs NIXL

What Is Mooncake

Mooncake has two components. They work at different layers of the stack.

Transfer Engine

The Transfer Engine handles P2P KV tensor movement between nodes using RDMA/RoCE. It is functionally similar to NIXL, with one difference: Mooncake manages its own routing layer on top of the raw transfer primitives. Instead of a direct pipe from prefill node A to decode node B, Mooncake's routing layer can redirect KV blocks to wherever they are needed based on the current pool state.

The Transfer Engine is the low-level substrate. MooncakeConnector in standard vLLM uses it for point-to-point prefill-to-decode handoff, the same pattern as NixlConnector. (MooncakeTransferEngineConnector is a separate connector available only in the vllm-omni subproject, not in standard pip install vllm.)

Mooncake Store

The Mooncake Store is the distributed KV object store. It aggregates underused GPU HBM, CPU DRAM, and NVMe from every node in the cluster into one logical pool. From any node's perspective, the Store is an addressable KV pool that happens to span many physical machines.

Why Moonshot built it: Kimi's agentic workloads run at production scale, processing 100B+ tokens per day with 1M-token context windows. At that scale, the KV cache for a single agent trace cannot fit on one GPU, and re-computing it per step would dominate cost. The Store keeps KV state alive across steps, across nodes, across prefill-decode boundaries.

The MooncakeStoreConnector (added in vLLM's May 2026 release) is the integration point. Prefill workers write computed KV blocks to the Store; decode workers read from it. Multiple prefill workers can write the same hot prefix, and multiple decode workers can read it without any coordination overhead. This is multi-producer multi-consumer KV sharing, which NixlConnector does not support.

How Mooncake Plugs into vLLM

vLLM uses a unified --kv-transfer-config JSON flag for all disaggregated KV connectors. The two Mooncake connectors follow the same interface.

MooncakeConnector

Point-to-point KV transfer using the core vLLM connector (available via standard pip install vllm). The prefill node is kv_producer, the decode node is kv_consumer. This is the simpler path: no Mooncake Store daemon required.

On the prefill node:

export VLLM_KV_TRANSFER_CONFIG='{
  "kv_connector": "MooncakeConnector",
  "kv_role": "kv_producer",
  "kv_connector_extra_config": {
    "decode_addr": "<DECODE_NODE_IP>:8201"
  }
}'

python -m vllm.entrypoints.openai.api_server \
  --model meta-llama/Llama-3.1-70B-Instruct \
  --dtype fp8 \
  --tensor-parallel-size 1 \
  --kv-transfer-config "$VLLM_KV_TRANSFER_CONFIG" \
  --port 8200

On the decode node:

export VLLM_KV_TRANSFER_CONFIG='{
  "kv_connector": "MooncakeConnector",
  "kv_role": "kv_consumer",
  "kv_connector_extra_config": {
    "prefill_addr": "<PREFILL_NODE_IP>:8200"
  }
}'

python -m vllm.entrypoints.openai.api_server \
  --model meta-llama/Llama-3.1-70B-Instruct \
  --dtype fp8 \
  --kv-transfer-config "$VLLM_KV_TRANSFER_CONFIG" \
  --port 8201

Note: always check your specific vLLM release notes for the correct connector option format, since the API surface for disaggregated connectors is evolving across minor releases. For the full MooncakeConnector usage guide, see docs.vllm.ai.

MooncakeStoreConnector

The full Store-backed path. Prefill workers write KV blocks to the Mooncake Store daemon; decode workers pull from it. This requires running a separate mooncaked daemon.

On the prefill node:

export VLLM_KV_TRANSFER_CONFIG='{
  "kv_connector": "MooncakeStoreConnector",
  "kv_role": "kv_producer",
  "kv_connector_extra_config": {
    "mooncake_store_addr": "<STORE_NODE_IP>:50051"
  }
}'

python -m vllm.entrypoints.openai.api_server \
  --model meta-llama/Llama-3.1-70B-Instruct \
  --dtype fp8 \
  --tensor-parallel-size 1 \
  --kv-transfer-config "$VLLM_KV_TRANSFER_CONFIG" \
  --port 8200

On the decode node:

export VLLM_KV_TRANSFER_CONFIG='{
  "kv_connector": "MooncakeStoreConnector",
  "kv_role": "kv_consumer",
  "kv_connector_extra_config": {
    "mooncake_store_addr": "<STORE_NODE_IP>:50051"
  }
}'

python -m vllm.entrypoints.openai.api_server \
  --model meta-llama/Llama-3.1-70B-Instruct \
  --dtype fp8 \
  --kv-transfer-config "$VLLM_KV_TRANSFER_CONFIG" \
  --port 8201

The decode node does not need to know which prefill node wrote the KV blocks. The Store handles that routing. This matters when you add a second prefill node or swap one out: the decode nodes keep working with no config change.

Building a KV Cache Pool from HBM, DRAM, and NVMe

The Mooncake Store manages three tiers:

• GPU HBM (hot): KV blocks for active requests. Fast but scarce. 80GB on H100 SXM5.
• CPU DRAM (warm): Recently-evicted blocks and shared prefixes. ~256-512GB per node at PCIe bandwidth.
• NVMe (cold): Long-tail historical context and persistent prefix cache. 2-4TB at 6-12 GB/s.

The tiering is similar to LMCache's hierarchy, but Mooncake's memory routing layer manages eviction across the whole cluster pool rather than per-node. A hot block on node A can be fetched by node B from the Store rather than re-read from node A's local DRAM.

For single-node NVMe tiering without the distributed pool, NVMe KV cache offloading covers that use case without the distributed Store complexity.

Start the Mooncake Store daemon with the tiers you want to expose:

# On the store daemon node (or the decode node)
mooncaked \
  --port 50051 \
  --capacity-hbm 0 \
  --capacity-dram 256 \
  --capacity-nvme 2000 \
  --nvme-path /mnt/nvme/mooncake

--capacity-hbm 0 tells the daemon to not reserve GPU HBM for the pool - prefill workers manage their own HBM and write completed blocks out via the connector. Set --capacity-dram and --capacity-nvme to the available sizes in GB. The NVMe path must be a mounted high-bandwidth SSD (PCIe 4.0+, 6 GB/s sequential minimum).

Verify the daemon is running:

grpc_cli call <STORE_NODE_IP>:50051 \
  MooncakeStoreService.GetPoolStatus \
  "" --channel_creds_type=insecure

Multi-Node Deploy on Spheron: Step-by-Step

Hardware Sizing

Minimum viable setup: 1x H100 prefill + 1x H200 decode. The Store daemon can run on the decode node to avoid a third instance.

Total on-demand: $2.54 + $3.70 = $6.24/hr. Spot on prefill: $1.43 + $3.70 = $5.13/hr (the prefill node is the interrupt-tolerant leg since KV blocks are written to the Store before the prefill node finishes serving the request).

Pricing fluctuates based on GPU availability. The prices above are based on 04 Jul 2026 and may have changed. Check current GPU pricing → for live rates.

Networking: RDMA/RoCE is required for sub-millisecond KV transfer. Spheron instances within the same region can be provisioned with 25GbE or InfiniBand. For networking options and RDMA configuration, see the GPU networking guide. TCP fallback works but adds 5-20ms per transfer, which compounds across steps in an agentic trace.

Step 1: Provision Nodes

Log in to app.spheron.ai and provision two instances:

• Prefill node: H100 SXM5, same region
• Decode node: H200 SXM5, same region

For multi-node provisioning specifics, see Spheron LLM quick guides. Note both private IP addresses before proceeding.

Step 2: Install Dependencies

On all nodes:

pip install mooncake-transfer-engine vllm

# Verify
python -c "import mooncake; print(mooncake.__version__)"
python -c "import vllm; print(vllm.__version__)"

Mount NVMe on the decode/store node:

sudo mkdir -p /mnt/nvme/mooncake
sudo mount /dev/nvme0n1 /mnt/nvme

Step 3: Start Mooncake Store Daemon

On the decode node (or a dedicated store node):

mooncaked \
  --port 50051 \
  --capacity-hbm 0 \
  --capacity-dram 256 \
  --capacity-nvme 2000 \
  --nvme-path /mnt/nvme/mooncake \
  &> mooncaked.log &

Step 4: Start Prefill Node

On the H100 prefill node:

STORE_IP=<DECODE_NODE_IP>

export VLLM_KV_TRANSFER_CONFIG='{
  "kv_connector": "MooncakeStoreConnector",
  "kv_role": "kv_producer",
  "kv_connector_extra_config": {
    "mooncake_store_addr": "'"$STORE_IP"':50051"
  }
}'

python -m vllm.entrypoints.openai.api_server \
  --model meta-llama/Llama-3.1-70B-Instruct \
  --dtype fp8 \
  --gpu-memory-utilization 0.92 \
  --max-model-len 32768 \
  --kv-transfer-config "$VLLM_KV_TRANSFER_CONFIG" \
  --port 8200

Step 5: Start Decode Node

On the H200 decode node:

STORE_IP=<DECODE_NODE_IP>

export VLLM_KV_TRANSFER_CONFIG='{
  "kv_connector": "MooncakeStoreConnector",
  "kv_role": "kv_consumer",
  "kv_connector_extra_config": {
    "mooncake_store_addr": "'"$STORE_IP"':50051"
  }
}'

python -m vllm.entrypoints.openai.api_server \
  --model meta-llama/Llama-3.1-70B-Instruct \
  --dtype fp8 \
  --kv-transfer-config "$VLLM_KV_TRANSFER_CONFIG" \
  --port 8201

Step 6: Validate KV Transfer

Send a test request to the prefill node and confirm the decode node picks up the KV blocks:

curl http://<PREFILL_NODE_IP>:8200/v1/chat/completions \
  -H "Content-Type: application/json" \
  -d '{
    "model": "meta-llama/Llama-3.1-70B-Instruct",
    "messages": [{"role": "user", "content": "Summarize the state of KV cache disaggregation in 2026."}]
  }'

Check the Store daemon logs for incoming writes from the prefill node:

tail -f mooncaked.log | grep "block_write\|block_read"

You should see block writes from the prefill node and block reads from the decode node.

Benchmarks: Throughput, TTFT, and Cost

The 3.8x throughput, 46x TTFT, and 8.6x latency figures below are from the vLLM engineering blog (May 2026), measured on 12 GB200 (Grace Blackwell) GPUs running agentic trace benchmarks. A separate scaling test to 60 GB200 GPUs in the same source showed >95% KV cache hit rate at that scale. The Mooncake arXiv paper (2407.00079) reports its own benchmark results under different conditions: 1.7-2.9x throughput improvement and 1.4-2.1x TTFT reduction. On a 2-node H100+H200 Spheron setup, absolute numbers will differ, but the relative ordering holds.

Note: The 3.8x throughput and 46x TTFT figures are from the vLLM engineering blog's agentic benchmark on 12 GB200 GPUs, not a general vLLM deployment. Real results depend on workload, hardware, and how much KV state is being reused across steps. Qualify these numbers against your own workload before using them in capacity planning.

Cost comparison at Spheron pricing (2-node setup, on-demand):

Cost per unit throughput drops significantly when KV reuse is high. The more your workload reuses KV state across steps, the better this ratio gets.

Mooncake vs LMCache vs NVMe Offloading: When Each Wins

LMCache excels when the same prefix is fetched repeatedly by many workers. It is in production at Google Cloud GKE Inference. For a detailed guide on LMCache deployment, see LMCache on GPU cloud.

NVMe offloading alone (no inter-node sharing) is the right choice for single-node setups where concurrency, not inter-node transfer, is the bottleneck. The NVMe KV cache offloading guide covers that path.

Mooncake and LMCache are not mutually exclusive. You can use Mooncake's Transfer Engine for inter-node KV movement and LMCache's NVMe tier for persistent cold storage on each node.

Spheron Angle: More Users from the Same GPU Fleet

The core argument for Mooncake on a fixed GPU budget: you are paying for GPU HBM whether or not it is being used to hold active KV state. Most H100 HBM at any given second holds KV state from previous steps that will be needed again within the next few seconds but is not currently being processed.

Mooncake extracts that idle HBM capacity across the cluster into a shared pool. Instead of every node managing its own island of KV memory, the pool is one coherent resource.

Concrete example: with 2x H100 SXM5 at $2.54/hr each ($5.08/hr total), a chatbot serving 1M-token context agentic tasks without Mooncake might sustain 3-4 concurrent users before KV memory fills and new requests stall prefill. The same two nodes serving as a Mooncake disaggregated cluster, with the decode node's 141GB H200 HBM as the hot tier and NVMe as the cold tier, can handle substantially more concurrent steps before reaching the same bottleneck.

The economics: instead of renting a third H100 at $2.54/hr to scale throughput by adding a node, Mooncake lets you extract more from the nodes you already have by reusing computed KV state rather than recomputing it. At $3.70/hr for an H200 decode node, you get a higher-HBM pool that handles more concurrent decode steps per dollar than a third H100.

For teams running multi-step agentic pipelines, the Mooncake architecture directly matches the workload shape. For single-user chatbots with short prompts, it is over-engineered. Know your workload before adding the distributed Store complexity.

Mooncake's disaggregated KV pool runs best on bare-metal GPUs with direct NVMe access and low-latency RDMA networking. Spheron's H100 and H200 instances include both, with bare-metal access and no hypervisor overhead on storage I/O.
