vLLM vs SGLang 2026: RadixAttention vs PagedAttention Benchmarks

Whether vLLM or SGLang is the right inference engine for your workload comes down to one number: prefix overlap ratio. If more than 60% of your requests share a common prefix (a system prompt, a RAG document, a tool definition block), SGLang's RadixAttention delivers measurably lower latency. If your prompts are mostly unique, both engines land within 5% of each other on throughput and the decision comes down to model support breadth and operational simplicity.

This post is a direct two-engine comparison. For the three-way benchmark that also includes TensorRT-LLM (compilation overhead, peak throughput, cold start times), see the vLLM vs TensorRT-LLM vs SGLang benchmark guide.

TL;DR Decision Table

Three decision rules:

• If prefix overlap is above 60%, benchmark SGLang first. RadixAttention is on by default and the cache hit rate is visible immediately at /metrics.
• If you're running Blackwell (B200, GB200) or need Eagle3 speculative decoding, start with vLLM.
• If you're unsure, deploy vLLM. It's the safe default with the most complete documentation and community.

Architecture: What Actually Drives the Difference

PagedAttention (vLLM)

PagedAttention treats the KV cache like OS virtual memory. Rather than pre-allocating a contiguous VRAM block sized to max_model_len per request (which wastes 60-80% of allocated memory on typical workloads), it divides the cache into fixed-size blocks (16 tokens by default) and allocates them on demand as tokens are generated. When a request finishes, its blocks are freed immediately and returned to the pool.

The practical benefit: more concurrent requests fit in the same VRAM. A 70B model at FP8 on H100 SXM5 80GB leaves roughly 8-10GB for KV cache after weights load. With static allocation, that headroom might handle 8-12 concurrent requests at 4K context. With PagedAttention, the same headroom handles 40-60 concurrent requests because blocks are shared across the pool and released as soon as requests complete.

vLLM also has Automatic Prefix Caching (APC), enabled via --enable-prefix-caching. APC caches the KV blocks for the system prompt prefix and reuses them across requests that share that exact prefix. It's effective for the simple case of a fixed system prompt but doesn't handle branching conversation histories or variable-length prefixes as efficiently as RadixAttention.

RadixAttention (SGLang)

RadixAttention extends the block-based KV cache idea by organizing blocks in a radix tree indexed by token sequence. Each node in the tree represents a token prefix; child nodes extend the parent's sequence. When a new request arrives, SGLang walks the tree to find the longest matching cached prefix and begins computation at that branch point.

The result: workloads with prefix overlap avoid recomputing KV activations for the shared prefix entirely. A 512-token system prompt shared across 1,000 concurrent requests gets computed once. A 10-turn conversation reuses the KV state from turns 1-9 when computing turn 10.

Cache hit rate under RadixAttention scales with overlap ratio. At 80% prefix overlap across requests (c=1 single-request baseline; see the benchmark section for c=50 numbers):

For unique prompts with no overlap, RadixAttention adds no overhead and performance matches vLLM's PagedAttention within noise.

Architecture Comparison Table

Benchmark Setup

Hardware

All benchmarks below ran on a Spheron H100 SXM5 80GB instance at on-demand rates. Bare metal, no hypervisor. Host driver 590.48.01, CUDA 13.0 containers for both engines. NVLink present but not used (single-GPU runs). For other GPU options see the full GPU rental catalog.

Software

• vLLM: v0.18.0 (vllm/vllm-openai:v0.18.0). Benchmarks ran without VLLM_USE_V2_MODEL_RUNNER since v0.18.0 predates MRV2 general availability. For MRV2-enabled numbers, see the vLLM Model Runner V2 deployment guide.
• SGLang: v0.5.9 (lmsysorg/sglang:v0.5.9-cu130-runtime). RadixAttention on by default.
• Model: Llama 3.3 70B Instruct at FP8 precision. Weights: ~70GB, leaving ~8GB for KV cache on a single H100 80GB.
• Benchmark client: async aiohttp, 200 prompts per run, 60-second warmup before each measurement window, 3-minute measurement window per concurrency level.
• Concurrency levels: 1, 10, 50, 100 concurrent requests.

Two separate benchmark sets:

1. Unique-prompt workloads: each request uses a completely distinct prompt (no shared prefix). Tests raw scheduling and memory management efficiency.
2. Prefix-heavy workloads: 80% of requests share a 512-token system prompt prefix. Tests RadixAttention effectiveness.

Throughput Benchmarks: Unique-Prompt Workloads

No prefix overlap. Both engines are on equal footing here.

At unique-prompt workloads, the engines are effectively identical. The ~2-4% SGLang edge falls within run-to-run variance. Neither engine has a meaningful throughput advantage when prefix overlap is zero.

These numbers align with the three-way comparison post: vLLM at 1,850 tok/s and SGLang at 1,920 tok/s at 50 concurrent requests, same test setup.

Throughput Benchmarks: Prefix-Heavy Workloads (80% Shared Prefix)

80% of requests share a 512-token system prompt. This is where the engines diverge.

TTFT Comparison (p50 and p95)

At c=50, SGLang delivers a 37% lower TTFT p50 and 41% lower p95. This is RadixAttention in action: the 512-token shared prefix is computed once and cached; subsequent requests skip that prefill work entirely.

At c=10 with vLLM's APC (--enable-prefix-caching) enabled, the gap narrows to roughly 15-18%. For the simple shared-system-prompt case, APC closes most of the gap. For variable-length prefixes and branching conversations, the radix-tree organization remains more effective.

Cache Hit Rate vs TTFT Reduction (at c=50)

The TTFT reduction grows nonlinearly with overlap ratio because higher overlap means more requests land fully in cache. Below 40% overlap the advantage is marginal. Above 60%, it's consistently meaningful.

DeepSeek V4 and MoE Model Benchmarks

For MoE models, the relevant variable is expert parallelism alongside tensor parallelism. Both engines support this but with different flag sets.

Test configuration: DeepSeek V4 Flash (~284B total, ~13B active) at FP8 on 8x H100 SXM5 (from a multi-GPU Spheron instance). Tensor parallelism TP=8 with expert parallelism enabled: --tensor-parallel-size 8 shards attention and MLP layers across GPUs while --enable-expert-parallel routes MoE expert layers separately.

vLLM flags:

vllm serve deepseek-ai/DeepSeek-V4-Flash \
  --quantization fp8 \
  --tensor-parallel-size 8 \
  --enable-expert-parallel \
  --gpu-memory-utilization 0.90

SGLang flags:

python -m sglang.launch_server \
  --model-path deepseek-ai/DeepSeek-V4-Flash \
  --quantization fp8 \
  --tp 8 \
  --ep-size 8 \
  --mem-fraction-static 0.90

MoE performance on unique prompts is within 7% of each other. The shared-prefix advantage for SGLang holds at the same ratio as on dense models, meaning workload characteristics matter more than the model architecture when choosing between the two engines.

For teams running large MoE models, the MoE inference optimization guide covers expert parallelism tuning in more depth.

Structured Output: xgrammar vs Guided Decoding

Constrained decoding overhead is a second axis where the engines differ, particularly for agent workloads.

SGLang xgrammar

SGLang uses xgrammar as its default constrained decoding backend. xgrammar compiles the JSON schema to a grammar automaton once (20-50ms compilation time), caches the compiled grammar, and reduces per-token overhead to near-zero on subsequent requests with the same schema. For agent APIs where the same tool schema is called thousands of times per hour, grammar caching eliminates most of the overhead.

Enable with:

python -m sglang.launch_server \
  --model-path meta-llama/Llama-3.1-8B-Instruct \
  --enable-cache-report
# xgrammar is the default backend; no extra flag needed

Monitor cache hit rate with the sglang_grammar_cache_hit_rate Prometheus metric.

vLLM Guided Decoding

vLLM also defaults to xgrammar for guided decoding as of 2026. Outlines and lm-format-enforcer remain selectable backends, but xgrammar is the default. The slight SGLang advantage comes from grammar-cache behavior: SGLang reuses compiled grammar automata more aggressively, so per-request overhead on repeated schemas drops faster after warmup. For structured output workloads, see the structured output and function calling guide for detailed benchmarks across schema types.

Latency Overhead by Schema Complexity (c=8, Llama 3.1 8B, H100 SXM5)

After grammar cache warmup, SGLang's per-request overhead on repeated schemas drops close to zero. vLLM's xgrammar implementation also benefits from the grammar cache, but the overhead reduction is less pronounced on repeated schema calls.

Speculative Decoding and MTP Support

vLLM Eagle3 and EAGLE2

vLLM has mature support for speculative decoding via Eagle3 and EAGLE2. With MRV2 async scheduling (VLLM_USE_V2_MODEL_RUNNER=1), Eagle3 delivers 30-45% decode speedup on Llama 3.3 70B at low batch sizes (1-4 concurrent requests) and 15-20% at moderate concurrency (10-20 requests). Flags:

vllm serve meta-llama/Llama-3.3-70B-Instruct \
  --speculative-model meta-llama/Llama-3.3-70B-Instruct-Eagle3 \
  --num-speculative-tokens 5 \
  --speculative-draft-tensor-parallel-size 1

For the full Eagle3 setup guide, see Eagle3 speculative decoding on GPU cloud.

SGLang Speculative Decoding

SGLang has speculative decoding support but integration is less mature than vLLM's at v0.5.9. For latency-sensitive workloads that rely heavily on speculative decoding, vLLM is the safer choice in mid-2026.

Multi-Token Prediction (MTP)

Both engines support MTP draft heads for models that ship them (DeepSeek V4, GLM-5.2). MTP provides 1.5-2x decode throughput on supported models by predicting multiple tokens per forward pass using the model's own lightweight draft heads rather than a separate draft model. DeepSeek V4 ships with MTP heads; check the model's documentation for the verified number of draft heads available in each variant before assuming a specific prediction depth per step. For setup details, see the multi-token prediction deployment guide.

Hardware Readiness: Blackwell, FP8, NVFP4, Multi-GPU

Blackwell users should run vLLM today. The FlashAttention 4 backend landed in v0.17.0 and auto-enables on SM100/SM103 hardware, delivering a meaningful throughput gain over FA3 on B200 and B300 GPUs. The benchmark here ran v0.18.0, which already includes FA4. B200 SXM6 is currently available on Spheron starting from $7.37/hr on-demand and $5.34/hr spot. Spot instances can be reclaimed without notice, so plan for checkpointing and automatic restart logic in production workloads if running spot. For Blackwell deployments, B200 GPU rental on Spheron lists current availability.

Pricing fluctuates based on GPU availability. The prices above are based on 24 Jun 2026 and may have changed. Check current GPU pricing for live rates.

For non-Blackwell hardware (H100, H200, A100), both engines are on equal hardware footing.

Cost Per Million Tokens on Spheron

Formula: (hourly_rate / 3600) / (tokens_per_sec / 1_000_000) = cost_per_million_tokens

Unique-Prompt Workloads (c=50)

Prefix-Heavy Workloads (80% shared prefix, c=50, effective throughput including cache savings)

H200 SXM5 spot pricing ($3.31/hr) puts SGLang's cost for prefix-heavy workloads at around $0.29/1M tokens, well below managed inference API pricing for open-source models. For a full cross-GPU cost-per-token analysis, see the GPU cost per token benchmark.

Pricing fluctuates based on GPU availability. The prices above are based on 24 Jun 2026 and may have changed. Check current GPU pricing for live rates.

When to Run Both Behind an Inference Router

High-traffic APIs often serve mixed workloads: some users run chatbots with shared system prompts (ideal for SGLang), others run batch classification jobs with unique prompts (roughly equivalent on both). Running a single engine optimizes for one use case at the expense of the other.

One approach: deploy both engines and route at the request level using LiteLLM or a custom gateway that reads a header or workload tag. Requests flagged as prefix-heavy go to the SGLang fleet; unique-prompt requests go to vLLM. Both expose the same OpenAI-compatible API, so the routing layer is a simple proxy change.

A simpler version: run SGLang for your customer-facing chat API and vLLM for your internal batch inference pipeline. Both pull from the same model weights on shared NFS or S3.

Migration Notes

vLLM to SGLang

Both engines expose an OpenAI-compatible API at /v1/chat/completions and /v1/completions. Your client code does not change. The only changes are at the container level:

Both load HuggingFace model format from Hub or local directory. No checkpoint conversion required.

SGLang to vLLM

Reverse the flag mapping above. If you were relying on RadixAttention's high cache hit rates for prefix-heavy workloads, add --enable-prefix-caching to the vLLM command. Expect TTFT to increase 15-40% on prefix-heavy workloads depending on prefix length and overlap ratio.

Summary

vLLM and SGLang are close enough in raw throughput that the decision rarely comes down to peak tokens per second on unique prompts. It comes down to workload characteristics and what you need to optimize.

SGLang wins when prefix overlap is above 60%, when you're running multi-turn agents or RAG pipelines, and when structured output schemas are repeated at high volume. vLLM wins when you need the broadest model support, Blackwell-native performance, or mature Eagle3 speculative decoding. For everything else, either engine gets you to production.

For deployment guides, see the SGLang production deployment guide and the vLLM production deployment guide.
